WCB Carbon Steel Lift Check Valve H41H-16C DN100 PN16 Flanged
WCB cast steel flanged lift check valve, H41H-16C, DN100, PN16, GB standard, gray painted.
描述
This WCB lift check valve provides reliable backflow prevention with a guided piston disc. Suitable for horizontal and vertical piping runs in industrial, chemical and water treatment systems.
- Body Material: WCB Cast Carbon Steel
- Size: DN100 (4″)
- Pressure: PN16 (Class 150)
- End Connection: RF Flanged (GB/T 9113)
- Model: H41H-16C
- Bonnet: Bolted Bonnet
- Disc: Stainless Steel 304
- Standard: GB/T 12235, GB/T 13927
- Temperature Range: -29??C to +425??C
- Coating: Grey Epoxy Painting
其他信息
| 重量 | 18 公斤 |
|---|---|
| Material | WCB Cast Carbon Steel |
| Pressure | PN16 |
| Size | DN100 |
