CF8 Stainless Steel Electric Actuated Gate Valve Z941W-10P DN150 PN10
CF8/304 stainless steel flanged gate valve with electric actuator, DN150, PN10, GB standard.
描述
This CF8 (304) Stainless Steel flanged gate valve is manufactured to Chinese GB standard. The rising stem (OS&Y) design provides clear visual indication of valve position. Suitable for water treatment, chemical, pharmaceutical, food and general industrial piping systems.
- Body Material: CF8 (304) Stainless Steel
- Size: DN150
- Pressure: PN10
- End Connection: RF Flanged (GB/T 9113)
- Actuation: Electric Actuator
- Stem: Rising Stem (OS&Y)
- Standard: GB/T 12234, GB/T 13927
- Temperature Range: -20??C to +200??C
其他信息
| Material | CF8 (304) Stainless Steel |
|---|---|
| Pressure | PN10 |
| Size | DN150 |
